Telemetry rollups over a fixed hierarchy
Sensors report to servers, servers to racks, racks to a facility. The totals at each level are sums or maxima over a fixed tree. When a few readings move, only the branches above them need to update.
What was measured
A windowed aggregation over 4,096 sensors in a fanout-4, six-level tree, rolling into 1,365 groups. The baseline is stock Kafka Streams, running the same aggregation. Both were run on the same machine.
| Measure | Result |
|---|---|
| Drain time | about 15 times faster (21 times once warm) |
| Staleness, 99th percentile | from 10.9 seconds to 107 milliseconds |
| CPU use | 38.2% lower |
| Resident memory | 60.5% lower |
| Energy for the same work | 2.1 times higher |
How to read the result
Most of the drain gain comes from the pipeline design. The stock version fans out events, serializes them, moves them between processes over the network, and keeps its state in RocksDB. The Delta Routing version runs in one process over an in-memory array. We have not yet measured how much of the gain comes from the update rule alone, against an in-process dense accumulator. That comparison is the next measurement.
The energy result runs the other way. The in-process version uses more energy on this workload, and we report it here alongside the time result.
Conditions
- Host: Intel Core i7-1165G7, performance governor, turbo disabled.
- Runtime: Temurin 25 for the Kafka Streams baseline.
- Scope: one aggregation pipeline on synthetic sensor events. Not a production deployment.
Where this applies
Use Delta Routing for rollups where the hierarchy is fixed, updates are small and frequent, and the current pipeline pays for fan-out, serialization or state storage on every step.
